- Brand: Selec
- Model: DXT541
- Display: 3+3 digits, 7 segment LED dual display (Upper: Red, Lower: Green)
- Functions: Multifunction Timer with ON delay, Interval, Cyclic ON first, and Cyclic OFF first modes
- Time Ranges: 9.99/99.9/999 sec, 9.59 min:sec, 99.9/999 min, 9.59 hr:min, 99.9/999 hr
- Counting Direction: Up/Down selectable
- Start Input: Gate / Pulse (Programmable)
- Reset: Front, Remote, and On power interruption (Programmable)
- Output: 2 x SPDT Relay contacts
- Contact Rating: NO: 10A 250 VAC/24 VDC; NO/NC: 5A/5A 250 VAC/24 VDC
- Memory Retention: 10 years
- Size: 48 x 48 mm compact panel mount
- Panel Cutout: 46 x 46 mm
- Application: Industrial automation and timing control
Selec DXT541 Digital Timer 3 Digit Single Display 90-270V AC/DC
