- Brand: Multispan
- Model No: TC-29AL
- Size (H x W x D): 72 x 72 x 85
- Display: Upper: 7 segments, 4 digits, 0.39″ RED LED display – Process value, Lower: 7 segments, 4 digits, 0.28″ GREEN LED display – Set value
- Input Sensor: J / K Model, PT-100 Model
- Output Control Output: 1 – Relay & SSR Both Parallel
- Relay Ratings: 1C/O, 5A, 230V AC
- SSR / Buzzer: 12V DC approximately
- Set Point: 1 – Set Point
- Control Action: PID / ON-OFF / TP (Configurable)
- Operating Mode: Heat Mode
- Resolution: J and K 1?C Fix, PT-100 2W/3W 1?C/0.1?C
- Accuracy: ?1% of FSD
- Power Supply: 90 – 270V AC/DC, 50/60 Hz, SMPS
- Enclosure Material: Plastic
- Operating Ambient Temp: 0?C – 55?C
