Kusam Meco Clamp On Earth Resistance Tester KM 1720 (Upgraded), with 0.00mA to 35A Leakage Current Range

Name: Kusam Meco Clamp On Earth Resistance Tester KM 1720 (Upgraded), with 0.00mA to 35A Leakage Current Range
Brand: Kusam Meco
SKU: Kusam Meco KM 1720
Price: 38940.00 INR
Availability: InStock

SKU: Kusam Meco KM 1720

₹38,940.00

Are You an International Customer?

Click here to reach out to us directly via WhatsApp.

Add to compare

Add to wishlist

Payment Methods:

Description

Brand: Kusam Meco
Model: KM 1720
Function: Digital Clamp On Earth Resistance and Leakage Current Tester
Resistance Measurement Range: 0.01 Ohms to 1200 Ohms
Maximum Resistance Measurement Resolution: 0.001 Ohms
Current Measuring Range: 0.00mA to 20.0A
Measured Current Frequency: 50/60Hz
Setting Range of Resistance Alarm Critical Value: 1 to 199 Ohms
Setting Range of Current Alarm Critical Value: 1 to 499mA
Jaw Opening Size: 32 mm
Max Bus Bar Dimension: 32 mm x 65 mm
Display: 4 digit LCD Backlight, 47 mm x 28.5 mm
Sampling Time: 1 second
Calibration: Automatic self calibration
Storable Measurement Data: 99 Units
Protection Grade: Double insulation
Operating Temperature: -10°C to 55°C
Power Supply: 4 X AAA alkaline dry battery (6V)
Dimensions: 285(L) x 85(W) x 56(H) mm
Weight: 1160g (inclusive of battery)
Accessories Included: Standard Testing Coil (5.1 Ohms), Strong Carrying Case, Batteries & User Manual
