Kusam Meco Arbitrary Waveform Generator KM 3022B, 25MHz with 7-Digit 4.3 Inch Color TFT LCD Display & 80MHz Frequency Counter

Name: Kusam Meco Arbitrary Waveform Generator KM 3022B, 25MHz with 7-Digit 4.3 Inch Color TFT LCD Display &amp; 80MHz Frequency Counter
Brand: Kusam Meco
SKU: Kusam Meco KM 3022B
Price: 38096.30 INR
Availability: InStock

SKU: Kusam Meco KM 3022B

₹38,097.00

Are You an International Customer?

Click here to reach out to us directly via WhatsApp.

Add to compare

Add to wishlist

Payment Methods:

Description

Brand: Kusam Meco
Model: KM 3022B
Primary Function: Arbitrary Waveform Function Generator
Frequency Range: 25 MHz sine wave frequency, 15 MHz square wave frequency
Waveform Length & Resolution: 2M waveform length, 16-bit resolution
Built-in Functions: Sine, square, triangle, pulse, noise, harmonic, and frequency sweep/burst capability
Arbitrary Waveforms: Built-in more than 160 arbitrary waveforms (including exponential rise/fall, ECG, gauss, haversine, Lorentz, dual-tone, DC, etc.)
Modulation Support: AM, DSB-AM, FM, PM, ASK, FSK, PSK, BPSK, QPSK, 3FSK, 4FSK, OSK, and PWM modulations
Harmonic Generator: Built-in high-order harmonic generator (at most 16-order harmonics)
Abundant I/O: Waveform output, sync signal output, modulation input, 10MHz external time base input/output, and trigger input/output
Interface & Programming: USB remote interfaces, SCPI compatibility for easy instrument programming, and waveform creation PC software included
Display: 4.3-inch color TFT LCD screen
Frequency Counter: Built-in 7 digit / second high resolution 80MHz frequency counter
Operating Temperature: 0 °C to 45 °C
Storage Temperature: -20 °C to 60 °C
Pollution Degree: 2
Power Consumption: < 30W
Dimension: Approx. 310(L) x 260(W) x 110(H)mm
Weight: Approx. 3 kg
