- Brand: GIC
- Model: HM110B-0000
- Function: Provides human-machine interface for PLC monitoring and control
- Display Type: 10.1″ TFT LCD (65535 colors)
- Resolution: 1024 x 600 pixels
- Supply Voltage: 24V DC (-15% to +20%)
- Power Consumption: 6.5W maximum
- Processor: Cortex-M7 (600MHz)
- Memory: 32MB ROM and 32MB RAM
- Touchscreen: 4-wire resistive, > 1,000,000 operations
- Communication Ports: COM1 (RS232/RS485) and COM2 (RS422/RS485)
- USB Interface: 1 x USB Slave Ver 2.0 and 1 x USB Host Ver 2.0
- Ethernet: Not applicable in this specific model
- SD Card Support: Not applicable in this specific model
- Real Time Clock (RTC): Built-in with 2 sec/day typical accuracy
- Environmental Protection: IP 65 degree of protection
- Operating Temperature: 0°C to +50°C
- Dimensions: 273mm x 203mm x 38mm
- Panel Cutout: 255mm x 185mm
GIC HM110B-0000 Human Machine Interface 24VDC 10.1” TFT display
₹39,586.00
