- Brand: GIC
- Model: G8XDTR4
- Primary Function: Nx-Comm RS 485 Communication Module for Smart Relay Genie-Nx
- Supply Voltage: 12-24 VDC
- Input Interface: TTL Level
- Output Protocol: RS 485 Protocol (Two wires, D+, D-)
- Communication: Modbus RTU (Slave)
- Baud Rate: 300, 600, 1200, 2400, 4800, 9600
- Capacity: Supports up to 32 Standard unit nodes
- Isolation Voltage: 2000 Vrms
- LED Indications: Red LEDs for Tx & Rx; Green LED for Power
- Operating Temperature: -10°C to +55°C
- Dimensions: 36.0mm Width x 90.0mm Height x 60.0mm Depth
- Weight: 84 g (unpacked)
- Certification: CE and UL Listed
GIC G8XDTR4 NX Process Module Genie Communication 12-24 VDC
₹1,704.00
