-17%
- Brand: TRINITY
- Model No: SLM PRO
- Display: 4×3,7 Segment, bright Red
- Power Supply: 60-480 V AC/DC,50-60 Hz
- Operating Temperature: 0 deg C to 55 deg C
- Parameters: KW,KVA,KVAR and Avg. Amps
- Window: 15 minutes or 30 minutes selectable
- Range of Reading: 0.05 to 1.00 Lag/Lead (Power Factor),0 to 999999999.9 (KWh/KVAh/KVARh)
- Mode: Fixed or Sliding selectable
- Panel Cutout: 92 X 92 mm
- Operating Current Range: 0.4% to 120% of CT primary
- Weight: 310 gms (Approx)
- Depth of Installation: 55 mm
- Power Factor Accuracy: 0.5% of Reading(For IPFI greater than 0.5)
- Bezel: 96 X 96 mm
- Active Power Accuracy: 0.5% of Reading(For IPFI greater than 0.5)
- Burden: 0.5 VA (Voltage), Less than 1.0 VA (Current)
- Secondary Current Input: 5A or 1A (Site Selectable)
- Direct Voltage Input: Upto 25 to 500V L-L,20 to 300V L-N
- Input Supply: Three Phases and Neutral (3P4W system)/Three Phases (3P3W system)/Single Phase and Neutral (1P2W)
- Overload: 5A CT (6A RMS Continuous),1A CT (1.2A RMS Continuous)
- Line Frequency: 45 to 55 Hz,0.05% of Reading (Accuracy)
- Reactive Power Accuracy: 1.0% of Reading
- Current Accuracy: 0.25% of Reading
- Voltage Accuracy: 0.5% of Reading
- Apparent Power Accuracy: 0.5% of Reading
