- Brand: Selec
- Model: MFM384-C-D-CE-CL05-Plus
- Size: 96 x 96mm
- Display Type LCD with Backlight, Bargraph Representation for Current
- Display Configuration 4 Rows of 4 Digits, 1 Row of 8 Digits
- Electrical Connection 3? ? 3W, 3? ? 4W, 2? ? 3W, 1? ? 2W
- Type of Output Pulse Output
- Features %THD up to 31st Level, Max/Min Demand (Power), Max Demand Current, Phase Sequence Detection
- Communication Protocol RS485 and MODBUS RTU
- CT Primary 1 / 5A to 10kA (Programmable for Any Value)
- CT Secondary 1 / 5A ( Programmable )
- PT Primary 100V to 500kV (Programmable for Any Value)
- PT Secondary 100V to 500V (Programmable for Any Value)
- Rated Input Current Nominal 5A AC (Min ? 11mA Max ? 6A)
- Supply Voltage 85 to 300V AC (45/65Hz)
- Mounting Type Panel Mount
- Certification CE RoHS, UL & MID
