- Brand: Multispan
- Model: MSU-1244U-M1
- Primary Function: 4 Channel Scanner with USB Data Logger and RS-485 Communication
- Inputs: Configurable for J & K Thermocouples, PT-100/PT.1 RTD, and Analog (0-10V DC, 0-20mA DC, 4-20mA DC)
- Input Range: J (0 to 600°C), K (0 to 1200°C), PT-100 (-99 to 400°C), PT.1 (-99.0 to 400.0°C), Analog (-999 to 9999)
- Outputs: 4 Relay (NO-C-NC) 5A @ 230V AC resistive load
- Communication: RS-485 RTU MODBUS and USB Port for data logging
- Supply Voltage: 100 to 270V AC, 50/60 Hz (Approx 7VA)
- Display: Dual 4-digit LED; Upper 0.70″ Red, Lower 0.50″ Green
- Size: 100 (H) x 100 (W) x 70 (D) mm
- Panel Cutout: 92 x 92 mm
- Operating Temperature: 0°C to 55°C
Multispan MSU-1244U-M1 Process Scanner And Data Logger 100-270V AC Supply 96X96
₹18,501.00
