- Brand: Multispan
- Model: MS-L14
- Product Category: 8 Channel Process Scanner
- Display: $320 times 240$ Px Resistive Touch Screen Display
- Input Types: Thermocouple (J, K), RTD (PT-100 2/3-Wire), and Analog (0-10V DC, 0-20mA/4-20mA DC)
- Measurement Range: J: 0 to $600^{circ}C$, K: 0 to $1200^{circ}C$, RTD: $-99^{circ}C$ to $400^{circ}C$, Analog: -999 to 9999
- Resolution: 16-Bit ADC Resolution
- Control Output: 4 Relays with Grouping Facility
- Relay Rating: 10A @ 230V AC / 30V DC
- Supply Voltage: 20V to 36V DC
- Power Consumption: 5VA
- Mechanical Dimensions: $101 times 101 times 71$ mm
- Panel Cutout Size: $92 times 92$ mm
- Accuracy: $pm 1%$ FSD
- Protection Rating: IP 65 (Front Side)
- Body Material: Polycarbonate (PC) Enclosure / ABS
- Applications: Pharma & Chemical industry, Generator monitoring, Remote terminal unit (RTU) for SCADA, and Machine Condition Monitoring
Multispan MS-L14 Process Scanner And Data Logger 20-36V DC Supply 96X96
₹13,696.00
