- Brand: Multispan
- Model: CC-522
- Control Action: ON-OFF with adjustable Hysteresis (0.1 to 20.0°C)
- Operating Modes: Selectable Cooling or Heating
- Input Sensor: NTC Sensor (10k ohm nominal resistance)
- Temperature Range: -50.0°C to 99.9°C
- Accuracy: ± 1% Full Scale Deflection (FSD)
- Relay Output 1 (Compressor): 20A @ 230V AC / 28V DC (Resistive Load)
- Relay Output 2 (Alarm): 5A @ 230V AC / 28V DC (Resistive Load)
- Display: 3-digit, 0.62″, 7-segment LED (Red or White options)
- Auxiliary Supply: 230V AC, 50/60 Hz (Power consumption 3VA max)
- Dimensions: 37 x 78 x 70 mm (HxWxD)
- Panel Cutout: 30 x 71 mm
- Environmental Limits: 0 to 55°C Operating; 95% RH Non-condensing
- Construction: Polycarbonate (PC) body with M3 terminal screws
- Applications: Deep Freezers, Display Cabinets, Chillers, and Heat Pumps
Multispan CC-522 Cryo Cooling Controller 230v AC Supply 37X78
₹2,036.00
