- Brand: Multispan
- Model: CC-521
- Primary Application: Designed for Deep Freezers, Chillers, Display Cabinets, and Heat Pumps.
- Input Sensor: NTC Sensor with a 10k ohm nominal resistance.
- Temperature Range: -50.0°C to 99.9°C.
- Measurement Accuracy: ± 1% of Full Scale Deflection (FSD).
- Control Action: ON-OFF control with adjustable hysteresis from 0.1 to 20.0°C.
- Output Configuration: 2 Relays (NO-C-NC contacts) rated at 10A @ 230V AC / 28V DC Resistive Load.
- Supply Voltage: 230V AC, 50/60 Hz (Factory set options for 24V DC or 12V DC available).
- Power Consumption: Maximum 3VA @ 230V AC.
- Display: 3-digit, 0.62″ 7-Segment LED display available in Red or White.
- Mechanical Dimensions: 37mm (H) x 78mm (W) x 70mm (D).
- Panel Cutout Size: 30mm (H) x 71mm (W).
- Defrost Features: Configurable defrost units (minutes/seconds), frequency (1-99 hours/minutes), and duration (1-99 minutes/seconds).
- Environmental Limits: Operating temperature from 0 to 55°C and up to 95% RH non-condensing.
Multispan CC-521 Cooling Controller 37X78
₹2,090.00
