- Brand: Multispan
- Model: APFC-114
- Primary Function: Automatic Power Factor Controller with 14-stage capacitor relay outputs
- Input Voltage: 300V to 520V AC (L-L)
- Current Sensing: 1 CT Sensing with primary ratio selectable from 5 to 9999 Amp
- Secondary Current: 10mA to 5 Amp (Without CT)
- Display: Dual 7-segment display (Upper: 4-digit 0.60″, Lower: 7-digit 0.38″)
- Outputs: 14 Stage Capacitor Relay (NO-C type), Rating: 7A at 250V AC
- Operating Modes: Kvar, Intel, and Manual modes
- Control Range: Target PF 1.000 Lag to -1.000 Lead
- Programmable Hysteresis: 0 to 25 KVAr
- Scan Time: Adjustable from 1 to 999.9 seconds
- Accuracy: Class 0.5 (Standard)
- Dimensions: 144(H) x 144(W) x 80(D) mm
- Panel Cutout: 138 x 138 mm
Multispan APFC-114 Automatic Power Factor Controller 144X144
₹8,750.00
