- Brand: Minilec
- Model: WLC D1
- Function: Water Level Controller / Moisture Control Relay
- Auxiliary Supply: 24 VAC/DC, 100-120/220-240/380-440 V AC ± 10%, 50 / 60 Hz
- Input Sensors: 3 Electrodes (Conductivity based)
- Output Contacts: 1 Changeover (1 CO)
- Contact Rating: 5A @ 230 V AC (Resistive)
- Sensitivity: Adjustable range from 1k $Omega$ to 200k $Omega$
- Trip Time Delay: Less than 1 second
- Dimensions: 76 x 30.5 x 117.5 mm (Overall)
- Mounting: 35 mm rail mounting or 68 mm centre to centre
- Sensor Size: 24 mm Diameter x 76 mm Length
- Weight: Unit – 300 gms, Sensor – 50 gms each
- Applications: Garment Machineries, Textile Machineries, Booster Pump Control Panels, Water Distribution Pump House, Water Cooled Machines
Minilec WLC D1 Water Level Controller Single tank 76X30.5
₹1,431.00
