- Brand: Minilec
- Model: VSP D1
- Function: Phase Failure, Phase Sequence, and Phase Unbalance Protection
- System Supply Voltage: 100-120 / 220-240 / 380-440 V AC ± 20%, 50/60 Hz
- Auxiliary Supply: 100-120 / 220-240 / 380-440 V AC ± 20%
- Output Contacts: 1 Changeover (1 CO)
- Contact Rating: 5A @ 230 V AC (Resistive)
- Trip Setting (Phase Unbalance): 40 V ± 6 V (Fixed)
- Trip Time Delay: 3.5 sec ± 1.5 sec
- Resetting Mode: Auto Reset
- Enclosure Dimensions: 76 x 30.5 x 117.5 mm
- Mounting: 35 mm Rail Mounting (68 mm centre to centre)
- Weight: 320 gms
- Applications: Hoist Motor Control, 3 Ph. Split AC machines, Agricultural Pump Starters, Machine Tools, Valve Actuator Motors, Injection Molding M/C
Minilec VSP D1 Phase Failure Relay 1CO 76X30.5
₹1,100.00
