- Brand: Minilec
- Model: VPG D1
- Function: Comprehensive protection for 3-Phase pumps combining Voltage Sensing and Water Level Sensing.
- System Supply Voltage: 415 V AC $pm$ 20%, 50 Hz $pm$ 3%
- Auxiliary Supply: Built-in
- Output Contacts: 1 CO (Changeover)
- Contact Rating: 5A @ 230 V AC (Resistive)
- Trip Settings: Phase Sequence (Yes), Phase Unbalance ($40text{V} pm 6text{V}$ fixed)
- Trip Time Delay: 3.5 sec. $pm$ 1.5 sec. for Phase Failure/Unbalance and Level Sensing
- Resetting Mode: Auto Reset
- Dimensions: $76 times 30.5 times 117.5 text{ mm}$ (Overall L x W x D)
- Mounting: 35 mm Rail Mounting or Panel Mounting ($68 text{ mm}$ centre to centre)
- Weight: 300 gms.
- Application: Ideal for Open well Pumps and Agricultural Pump Starters to prevent dry running and electrical faults.
Minilec VPG D1 Phase Failure Relay with Water Level Guard
₹1,415.00
