- Brand: Minilec
- Model: S2 VMR7
- Primary Protection Functions: Phase Failure, Phase sequence reversal, Phase Unbalance, Under voltage, and Over voltage
- System Supply Voltage: 380/400/415 VAC, 3 Phase, 3 Wire
- Auxiliary Supply Voltage: In-Built from three phase
- Frequency: 48 to 63 Hz ± 3%
- Output Relay Contacts: 2 CO (Changeover)
- Output Contact Rating: 5 Amp, 240VAC (Resistive)
- Under Voltage Trip Setting (Ph-Ph): 90% of System Supply
- Over Voltage Trip Setting (Ph-Ph): 110% (380/400 VAC) or 109% (415 VAC) of System Supply
- Unbalance Trip Setting: 10% + 10% of set value
- Trip Time Delay: 2-5 Sec for UB/UV/SP and Instant for RP/OV
- Dimensions (W x H x D): 35 x 90 x 60 mm
- Mounting: DIN Rail
- Operating Temperature: -5°C to +60°C
Minilec S2 VMR7 Phase Failure Relay with Fixed Under and Over Voltage 35X90
₹2,305.00
