- Brand: Minilec
- Model: S2 CMR1
- Supply Voltage: 100-120/220-240/415V AC ± 20%, 48 – 63 Hz; 24V DC (+10% to -15%)
- Output Relay Contact: 2 CO (Changeover)
- Contact Rating: 5A @ 230 V AC (Resistive)
- Input: From S2 CTS 1
- Trip Setting (Phase Unbalance): 50% of Motor Current (Fixed)
- Trip Setting (Under Current/Dry Run): 40% to 80% ± 5% of Set Current (Adjustable with Bypass)
- Trip Setting (Overload): As per IDMTL Characteristics
- Trip Time Delay (Phase Failure): 4 Sec ± 1 Sec (Fixed)
- Trip Time Delay (Overload): Selectable 2/5/10 Sec (As per IDMTL)
- Resetting Mode: Auto / Manual Selectable
- Dimensions: 90 x 35 x 60 mm (L x W x D)
- Mounting: 35 mm Rail Mounting
- Approx Weight: 140 gms
- Applications: Air-Conditioning & Refrigeration, Crusher Motors, Mining Machinery, Screw Compressors, Lifts, Elevators, Hoists, and Cranes.
Minilec S2 CMR1 Current Sensing Phase Failure Relay 90X35
₹2,995.00
