- Brand: Minilec
- Model: D5 PTW3
- Function: 3-Phase 3-Wire Power Transducer
- Auxiliary Supply: 24/48 VDC (+/-20%), Self Powered, 80-300 VAC/DC, 110V AC/DC, 220V AC/DC, 50 Hz
- Power Consumption: 3.5 VA (AC), 4 VA (DC)
- Input Current (I In): 1A / 5A
- Input Voltage (V In): 110V / 415V
- DC Output: Multi-range support (0-1mA, 0-20mA, 4-20mA, 0-10V DC, etc.)
- Number of Signal Outputs: Single (Optional Dual Output available)
- Response Time: Less than 500 milliseconds
- Input/Output Isolation: Galvanic Isolation
- Operating Temperature: 0°C to +55°C
- Enclosure & Protection: ABS Plastic, IP40 Ingress Protection
- Terminal Size: Suitable for 2.5 sq.mm wires
- Dimensions (L x W x D): 150 x 70 x 114 mm
- Weight: 1200 gms
- Compliance: IEC Standard 60688
- Application: Cogeneration/Captive Power Plants, Control & Relay Panels, Metering Panels, Paper Mills, Sugar Plants, Motor Testing Equipments
Minilec D5 PTW3 Three Phase Apparent Power Transducer 150X70
₹7,346.00
