- Brand: Minilec
- Model: D3 PTF1
- Primary Function: Voltage/Frequency to DC Output Transducer
- Auxiliary Supply: 24/48V DC (+/-20%) or 80-300V AC/DC, 50 Hz
- Nominal Input Voltage (Vin): 63.5V, 110V, 240V, 415V
- Input Frequency Range (Iin): 45-55 Hz, 40-60 Hz, 55-65 Hz, or 48-52 Hz
- DC Output Options: 0-1 mA, 0-10 mA, 0-20 mA, 4-20 mA, 0-5 V, or 0-10 V DC
- Output Configuration: Single Signal Output (Dual Output optional)
- Response Time: Less than 500 milliseconds
- Isolation: Galvanic Input/Output isolation
- Accuracy: High precision instrumentation grade
- Power Consumption: 3.5 VA (AC), 4 VA (DC)
- Operating Temperature: 0°C to +55°C
- Humidity: Up to 95% Rh non-condensing
- Dimensions: 75 x 56.5 x 117.5 mm (L x W x D)
- Enclosure: ABS Plastic, IP40 Ingress Protection
- Terminals: Suitable for 2.5 sq.mm wires
- Weight: 575 gms
- Standard Compliance: IEC 60688
- Application: Instrumentation Panels, Generator Panels, and Power Plant Control Panels
Minilec D3 PTF1 Line Frequency Transducer 75X56.5
₹4,470.00
