- Brand: Minilec
- Model: D2 VMR2
- Primary Function: Phase Failure, Phase Sequence, Phase Unbalance, Under Voltage (UV), and Over Voltage (OV) Monitoring
- Supply Voltage: 100-120 / 220-240 / 380-440V AC (System), Built-in Auxiliary
- Under Voltage Trip: 165-245V AC (for 380-440V) / 95-135V AC (for 220-240V) / 45-65V AC (for 100-120V)
- Over Voltage Trip: 230-310V AC (for 380-440V) / 130-170V AC (for 220-240V) / 60-80V AC (for 100-120V)
- Phase Unbalance: Adjustable from 4% to 20%
- Trip Time Delay: Phase Failure (Instant), UV/OV (1 to 10 Sec), NF (2 Sec ± 1.5 Sec)
- Output Contacts: 2 CO (Changeover)
- Resetting Mode: Auto / External Manual Reset (External NC Push Buttons)
- Dimensions: 76 x 56.5 x 117.5 mm (Overall)
- Mounting: 35 mm Rail Mounting / 67 x 46 mm
- Weight: 300 gms
- Application: AC & R Chiller compressors, AHU Fan/Pumps, Hoists, Cranes, DG Sets, and Submersible Pumps
Minilec D2 VMR2 Phase Failure Relay with Under and Over Voltage Relay 76X56.5
₹2,980.00
