- Brand: Minilec
- Model: D1 VCR1
- Function: Single Phase Voltage Monitoring (Over Voltage & Under Voltage Protection)
- System Supply: 110/220/230/240 V AC (+ 20% – 25%), 50/60 Hz ± 3%
- Output Contacts: 2 CO
- Contact Rating: 5A @ 230 V AC (Resistive)
- Under Voltage Trip Setting: 75% – 95% [Variable]
- Over Voltage Trip Setting: 105% – 120% [Variable]
- Trip Time Delay: 2 – 5 Sec
- Reset: Auto Reset
- Weight: 180 gms.
- Overall Dimensions (mm): 76 x 30.5 x 117.5
- Mounting (L x W): 68mm centre to centre / 35 mm rail Mounting
- Application: Battery Charger & Float Charger Panels, UPS for Office Computers, Telecom Power Supply Units
Minilec D1 VCR1 Single Phase Under and Over Voltage Relay 76X30.5
₹1,741.00
