- Brand: GIC
- Model: TCM3T100
- Technical Function: Digital Temperature Controller with Auto-tuning PID and Soft-Start provision
- Display: 4 Digit Single LED Display (Red, 14mm)
- Input Types: Universal Input supporting Thermocouples (J, K, T, R, S) and RTD (PT-100)
- Output: Configurable 10A SPDT Relay or SSR Drive (12VDC, 50mA)
- Supply Voltage: 90 to 270 VAC/DC at 47 to 63Hz
- Measurement Range: J (-199 to 750°C), K (-199 to 999°C), T (-199 to 400°C), R & S (0 to 999°C), PT-100 (-150 to 850°C)
- Dimensions: 72 x 72 x 65 mm (Panel Cutout: 68 x 68 mm)
- Control Methods: ON-OFF or PID with Heat/Cool controlling action
- Protection: IP 65 for Front Panel and IP 20 for Terminals & Enclosure
- Special Features: Multiple device programming via Memory Card and Rapid Set Point change
- Certifications: CE, UKCA, and ROHS Certified
GIC TCM3T100 Temperature Controller 4 digit single display
₹2,651.00
