GIC PC10ED16003N Programmable Logic Controller PLC Extension with 8 Relay Output

Name: GIC PC10ED16003N Programmable Logic Controller PLC Extension with 8 Relay Output
Brand: GIC
SKU: GIC PC10ED16003N
Availability: InStock

SKU: GIC PC10ED16003N

₹5,674.00

Are You an International Customer?

Click here to reach out to us directly via WhatsApp.

Add to compare

Add to wishlist

Payment Methods:

Description

Brand: GIC
Model: PC10ED16003N
Product Type: PLIO (Programmable Logic IO) Controller
Number of Channels: 4 Channel
Digital Inputs: Isolated Digital Inputs with sourcing & sinking capability
Digital Outputs: Isolated Digital Transistorized Outputs (Low Side and High side driver)
Analog I/O: 0-10 V / 4-20 mA Voltage and Current support
Communication Interface: Ethernet and RS485
Communication Ports: 2 COM ports (Standard RS232/RS485 via RJ11 & RS485 via screwing connector)
Communication Protocol: Modbus RTU (Master and Slave support)
Expandability: Supports up to 112 IOs via FRC cable stacking (maximum 6 modules)
Expansion Modules: Compatible with Relay Base & Transistor Low Side Base modules
Special Features: GSM support through expansion and physical RUN/STOP program switch
Function Blocks: 128 Weekly, Monthly & Yearly Time Switches; Multiple Timers, Counters, and Hour meters
Software: PC Software for programming, online/offline simulation, and monitoring
Mounting Type: DIN Rail
