- Brand: GIC
- Model: MAG03D0424
- System Configuration: Three Phase 3 Wire or Three Phase 4 Wire (Configurable)
- Supply Voltage: 208 – 480 VAC (3P-3W) / 120 – 277 VAC (3P-4W)
- Protection Functions: Phase Loss, Phase Sequence, Phase Asymmetry, Under Voltage (UV), and Over Voltage (OV)
- Trip Settings (UV/OV): Adjustable from 2% to 22%
- Asymmetry Setting: 10% Fixed
- Time Delay: Adjustable ON/OFF Delay (0 to 15 seconds)
- Output Contact: 1 C/O Relay
- Contact Rating: 5A @ 250 VAC / 30 VDC (Resistive)
- Enclosure Width: Compact 17.5 mm
- Mounting: Base or DIN Rail
- Indications: LED Indication for Power and individual Faults
- Certifications: CE
GIC MAG03D0424 Voltage Monitoring Relay SM 175 120-277 VAC 1 C/O
₹2,430.00
