- Brand: GIC
- Model: HM104B-N000
- Display Type: 4.3″ TFT LCD (65535 colors)
- Resolution: 480 x 272 pixels
- Supply Voltage: 24V DC (-15% to +20%)
- Power Consumption: 4.5W maximum
- Processor: Cortex-M7 (600MHz)
- Memory: 64MB ROM and 32MB RAM
- Communication Ports: COM1 (RS232/RS485) and COM2 (RS422/RS485) via single DB9 port
- USB Connectivity: 1 x USB Host Ver 2.0 and 1 x USB Slave Ver 2.0
- Ethernet: 1 x RJ45 Network Port (LAN)
- Storage Expansion: Supports SD Card
- Touchscreen: 4-wire resistive, > 1,000,000 operations
- Real-Time Clock (RTC): Built-in
- Dimensions: 136 x 102 x 36.5 mm
- Panel Cutout: 118.8 x 92.8 mm
- Protection Rating: IP65
- Operating Temperature: 0°C to +50°C
GIC HM104B-N000 Human Machine Interface 24VDC 4.3” TFT Display
₹20,809.00
