- Brand: GIC
- Model: 67DDT9
- Function: Digital Pulse Time Switch (Pulse Series)
- Supply Voltage: 110 to 240 VAC
- Supply Variation: -20% to +10%
- Power Consumption (Max.): 4 VA
- Operating Frequency: 50/60 Hz
- Contact Arrangement: 1 C/O (SPDT)
- Contact Rating: 16 A (NO) & 5 A (NC) @ 240 VAC/24 VDC (Resistive)
- Number of Programs: 16 ON Programs
- Pulse Duration: 01 to 59 seconds
- Clock Mode: 12h (AM/PM) or 24h Clock
- Clock Accuracy: +/- 2 s/day maximum over operating temperature range
- Display: 3 Line Text LCD
- Battery Backup: Approximately 6 years running reserve at 20 °C
- Mounting: Base / DIN Rail 35mm
- Dimensions: 36.0 mm Width x 90.0 mm Height x 65.0 mm Depth
- Operating Temperature: -10° C to +55° C
- Degree of Protection: IP-20 for Terminals; IP-40 for Enclosure
- Compliance: CE, RoHS
GIC 67DDT9 Digital Time Switch Pulse 110-240 VAC 1 C/O
₹3,230.00
