- Brand: GIC
- Model: 2SC3D11EC3
- Primary Function: Signal Transducer and Isolator with 3-port galvanic isolation
- Input Signal Options: 0-10VDC, 2-10VDC, 0-10mA DC, or 2-10mA DC (User selectable via DIP switch)
- Output Signal Options: 0-10VDC, 2-10VDC, 0-20mA DC, or 4-20mA DC
- Supply Voltage: 24VDC, +/-15%
- Isolation: 3.75kV AC galvanic isolation between input, output, and supply
- Accuracy: Accuracy Class 1 as per IEC60688 (1% of Full Scale)
- Response Time: Less than 100ms
- Input Impedance: 100k? approx. for Voltage / 200? approx. for Current
- Adjustments: Front-accessible potentiometers for Offset (+/-5%) and Gain (+/-10%) calibration
- Indicators: Green LED for Power-ON status
- Housing & Mounting: 22.5mm wide industrial housing for 35mm symmetrical DIN-rail mounting
- Terminal Protection: IP20 for terminals and IP40 for housing
- Operating Temperature: -10°C to +55°C
GIC 2SC3D11EC3 Signal Transducer 24 VDC
₹2,186.00
